GAC ADD180G-24 Engine-Mounted Actuator for Deutz and Volvo 24Volt Original

https://powermaster.odoo.com/web/image/product.template/10128/image_1920?unique=23f0e3f

24VDC / Packard Connector with Mating Connector EC1300 / Includes KT188 Installation Kit

$ 966.69 966.69 USD $ 966.69

$ 966.69

Not Available For Sale

This combination does not exist.

Contact Us
Actuator 24V ADD180G

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

POWER INPUT

12 or 24 V DC

RELATIVE
HUMIDITY
up to 100 %


WEIGHT
4.75 POUNDS
SIZE
8.7 x 6 x 4 Inches



ENVIROMENTAL

-40 to +212 °F

NORMAL OPERATING
CURRENT
2.0 A

OPERATING TEMPERATURE
 -40 to +212 °F (-40 to +100 °C)



WEIGHT
4.75 POUNDS

  • Power Input -  ◖Operating Voltage : 12 or 24 V DC  ◖Normal Operating Current : 2.0 A ◖Maximum Current Continuously Rated : 3.0 A
  • Performance -  ◖ Operating Stroke 0.78¨


  • Environment -  ◖ Operating Temperature Range : -40 to +212 °F (-40 to +100 °C) ◖Relative Humidity : up to 100 %  ◖All Surface Finishes : Fungus Proof and Corrosion Resistant  ◖Ingress Protection : IP65
  • Reliability  -  ◖ Testing :100 % Tested



  • The 180 Series Integral Actuator is designed to mount directly to Deutz 1013/2012 and Volvo 520/720 engines. The existing mechanical governor is removed from the engine and the 180 Series Integral Actuator is mounted in its place. GAC’s unique electromechanical technology provides proportional actuator movement based on actuator coil current. This unique, optimized fuel control will outperform externally mounted electric actuators.
