GAC ADD175A-24 Integrated P-Pump Mounted Actuator 24Volt Original

24VDC / Packard Connector without Mating Connector / Single Rack Bearing / Bosch Install Kit KT289 Included

This combination does not exist.

Actuator 24V ADD175A

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

12 V DC or 24 V DC

OPERATING TEMPERATURE
-40 to 200 °F [-40 to 95 °C]

4.75 POUNDS

Electrical Power Input / Output - ◖Operating Voltage : 12 V DC or 24 V DC ◖Nominal Operating Current : 2.0 A ◖MAX Continuous Current : 3.1 A ◖Nominal Coil Resistance : 7.1 Ω Nominal ◖Internal Sealing Pressure : 2 bar (29 psi) .
Performance - ◖Force :6.2 lbf∙ft [27.5 N∙m] ◖Operating Stroke : 0.80 in [21 mm] ◖Response Time : (10-90%, 2-19 mm) 35 ms ◖Internal Sealing Pressure : 2 bar (29 psi)

Environmental - ◖Operating Temperature : -40 to 200 °F [-40 to 95 °C] ◖Relative Humidity : Up to 100 % ◖Vibration :20 g @ 20 to 500Hz ◖Shock : 20 g @ 11 ms ◖All Surface Finishes : Fungus Proof and Corrosion Resistant

GAC’s 175 Series Integrated Pump Mounted Actuators are field proven proportional actuators designed to mount directly to fuel injection pumps in place of a mechanical governor to achieve an integrated proportional servo fuel package. The versatile design offers numerous options and mounting kits. Its fast response time of less than 35 ms (10 % - 90 %) also offers adjustable fuel limits. 12 or 24 V DC with Packard Connector without Mating Connector / Single / Bosch installation kit KT289 included
