  2. GAC ACD110-24 Engine Mounted Actuator for Deutz 1011 24Volt Original

GAC ACD110-24 Engine Mounted Actuator for Deutz 1011 24Volt Original

https://powermaster.odoo.com/web/image/product.template/10116/image_1920?unique=df81f6b

24VDC / Deutsch Connector without Mating Connector / Same as ACD110A

$ 589.19 589.19 USD $ 589.19

$ 589.19

Not Available For Sale

This combination does not exist.

Contact Us
Actuator 24V ACD110

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

POWER INPUT

12 or 24 V DC available


RELATIVE
HUMIDITY

Up to 100%



WEIGTH
1.5 POUNDS

SIZE
66 x 0.5 Inches





ENVIROMENTAL

-40 to 212 °F



NORMAL OPPERATING
CURRENT

2.0 A

OPERATING TEMPERATURE

-40 to 212 °F [-40 to 100 °C]

WEIGTH

1.5 POUNDS

  • Power Input -  ◖Operating Voltage : 12 or 24 V DC available ◖Normal Operating Current 2.0 A ◖Maximum Current (Continuous) : 3.5 A
  • Environmental -  ◖Operating Temperature Range : -40 to 212 °F [-40 to 100 °C] ◖Relative Humidity : up to 100 % ◖All Surface Finishes : Fungus proof and corrosion resistant
  • Reliability -  ◖Testing : 100 % Tested.
  • Mating Hardware -  ◖Wiring Harness : 2-wire with Automotive Connector (not included with actuator - CH1249-L02) ◖Mating Half Connector : Connector (included w/ ACE110 Series - EC1120)


The GAC 110 Series Integral Actuator is designed to mount directly to DEUTZ 1011 Series 2, 3, and 4 cylinder engines in place of the electric stop solenoid and is available in 12 and 24 V DC. This unique, optimum fuel control, actuating device outperforms externally mounted types of electric actuators. An integral high performance speed control system results when the 110 Series Electric Actuator is installed on the engine and electrically connected to complementing governor system components. No external linkages or brackets are required.

  • Mounts directly to Stanadyne D Series pump
  • No external linkages or brackets required
  • Functions as a fuel shutoff solenoid when governor system is de-energized
  • Faster response than competitive design


  • EEG6500 (Digital)
  • ECC328 (No MSP Required)
  • ESD2244
  • ESD2402
  • ESD5120
  • ESD5500-II
  • ESD5520E
  • ESD5570



Product Bulletin 100 Series

Installation Bulletin

Example ADC100 Installation (Video)

Spanish Installation Bulletin
