DSE 7450-02 DC/Hybrid Generator Control Module Original

https://powermaster.odoo.com/web/image/product.template/9981/image_1920?unique=9d29bf2

DSE7450 DC Generator Controller

$ 808.99 808.99 USD $ 808.99

$ 808.99

Not Available For Sale

This combination does not exist.

Contact Us
DSE DSE7450 Generator DSEGenset

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

DC SUPPLY
VOLTAGE RATING
8 V to 35 V
PRODUCT VARIANTS

7450-02 - 7450 DC/Hybrid Generator Control Module


WEIGHT
2.0 POUNDS
SIZE
9 x 6 x 2 Inches

FREQUENCY
RANGE

3.5 Hz to 75 Hz

CONFIGURABLE INPUTS/OUTPUTS (10/8)

Provides multiple installation options.

BACKED-UP REAL TIME CLOCK

Ensures data is not lost when module is disconnected from its power source.

AC/DC VOLTAGE MEASUREMENT

Provides flexibility for use on AC or DC systems.

  • Continous Voltage Rating - ◖8 V to 35 V Continuous
  • Cranking Dropouts- ◖Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved without the need for internal batteries
  • Maximum Operating Current - ◖260 mA at 12 V, 130 mA at 24 V
  • Maximum Standby Current - ◖120 mA at 12 V, 65 mA at 24 V
  • Charge Fail/Excitation Range - ◖0 V to 35 V
  • Output A (Fuel) - ◖15 A DC at supply voltage
  • Output B (Start) - ◖15 A DC at supply voltage
  • Outputs C & D - ◖8 A AC at 250 V AC (Volt free)


  • Auxiliary Outputs E,F,G,H,I & J - ◖2 A DC at supply voltage
  • Voltage Range - ◖15 V to 150 V AC (L-N)
  • Frequency Range - ◖3.5 Hz to 75 Hz
  • Mains (Utility) - ◖Voltage Range : 15 V to 333 V AC (L-N)◖Frequency Range : 3.5 Hz to 75 Hz
  • Magnetic Pick Up - ◖Voltage Range : ​+/- 0.5 V to 70 V ◖Frequency Range : 10,000 Hz (max)







The DSE 7450 is a control module designed to control DC/Hybrid generators in supplying both a load and/or the charging of batteries. Specific attention has been given to ensure this module has the necessary features to be configured for many different and challenging applications. Owing to the large number of monitoring points and the built in programmable logic controller, a wide number of operating modes can be realised. This provides the user with the ultimate flexibility in the engine control of the generator to ensure battery life optimisation, reduce engine maintenance/replacement and fuel usage.
