Hotstart CTM15110-N00 Original Engine Heater

https://powermaster.odoo.com/web/image/product.template/9727/image_1920?unique=2bcd88f

CTM 1500W 120V 100-120F NEMA

$ 769.99 769.99 USD $ 769.99

$ 769.99

Not Available For Sale

This combination does not exist.

Contact Us
Engine Heater Hotstart CTM15110-N00 HOT Flow COOLANT HOT Flow COOLANT System

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

POWER SUPPLY

120v 60Hz 1.5kW 13.0 Amps

 PART NUMBER

CTM15110-N00
1500W – 120V



WEIGHT

3,9 POUNDS

SIZE

12 x 8 x 8 Inches



MODEL AVAILABLE

UL/C-US
Compact design Easy to install






ENGINE DISPLACEMENT

 500-700 CID / 8-12 L

TEMPERATURE CONTROL

Fixed, 100-120°F (38-49°C)

FLUID TYPE

Water/Coolant mix (50% water, 50% glycol)

  • System - ◖Voltage (60 Hz): 120 V ◖Ingress: IP44 ◖Min./Max. Ambient Temp: -40°F/104°F (-40°C/40°C) ◖Application: for use in weather protected applications ◖Certification: UL/C-US recognized models available (E250789) CE-compliant models available



  • Coolant - ◖Fluid Type: Water Coolant mix (50% water/50% glycol) ◖Heat Power: 1.5 kW ◖Temp. Control: Fixed, 100 – 120 °F (38–49°C) ◖Temp. High Limit: 300 °F (149°C) ◖Flow: 3.5 gpm @ 4 psi (13.3 L/min @ 28 kPa) ◖Inlet/Outlet: 0.625” (16mm) hose barb


HOTflow TM model CTM was developed to pre-heat diesel and gas engines for stationary land power, marine and construction equipment. HOTSTART’s CTM HOTflow TM heating system is a complete coolant preheater. It features an integrated pump that combines the benefits of forced circulation with a compact design that can mount to a variety of small engine applications. The CTM model heats engines up to 20L displacement. Forced circulation of the coolant delivers uniform heating throughout the entire engine, extends element life and offers a significant reduction in electrical consumption.
